Flow Master N2

This project is designed to monitor nitrogen flow in industrial pipelines and automatically control a 230V, 16A load based on real-time flow conditions. A nitrogen flow sensor is installed at the end or along the pipeline to ensure accurate detection. The system continuously verifies whether the nitrogen flow meets the minimum required threshold and enables or disables the connected equipment accordingly. This enhances operational safety, prevents equipment malfunction, and ensures efficient nitrogen usage in industrial processes.

Applications :

Key Features :

✅ Real-Time Nitrogen Detection – Continuously monitors nitrogen flow using a high-precision sensor placed at the end or mid-section of t the pipeline.
✅ Minimum Flow Verification – Ensures the required nitrogen flow is present before activating downstream equipment.
✅ Automatic 230V/16A Load Control – Controls motors, valves, heaters, and machinery through a protected relay or contactor system.
✅ Fail-Safe Operation – Automatically disconnects the 230V load during low flow, no flow, or leakage conditions.
✅ Industrial-Grade Sensor Placement – Supports flexible installation at end-line or mid-pipe positions for accurate measurement.
✅ High Electrical Safety – Includes isolation, fuse/MCB protection, and surge handling for safe high-voltage control.
✅ Compact Embedded Controller – Microcontroller or PLC-based logic ensures fast response and reliable 24/7 operation.
✅ Low Maintenance & Long Life – Designed for long-term industrial use with minimal recalibration

✔️ Industrial gas supply systems
✔️ Nitrogen purging and blanketing operations
✔️ Chemical processing plants
✔️ Food and pharmaceutical packaging lines
✔️ Laboratory equipment using nitrogen supply
✔️ CNC machines and welding gas flow control
